Seats with a unique and innovative design
Thanks to our experience, for more than 30 years we have been offering a design service for new chairs following every request provided by the customer. The final product will therefore be a unique, innovative object with an Italian style, able to best meet all the needs of modern sports facilities.
Monocoque
Tip-up
Vip Armchairs
M2008
M2009
M2010
M2011
M2020
M2025
M90
Caravaggio
M2012
M2013
M2016
M2027
Botticelli
Leonardo Gold
Leonardo Silver
Monocoque seats
M2008
Dimensions: 440 x 350 x 350 mm
The M2008 model is a monocoque with a high backrest that allows the user to enjoy the sporting event in comfort, without sacrificing solidity and robustness.
It was the first on the market to comply with the minimum depth dictated by European standard UNI EN 13200-1: 350 mm. With this depth, the free passage between rows is respected even in a 700 mm step. Its 3 fixing points guarantee solidity, sturdiness and resistance to vandalism.
Monocoque seats
M2009
Dimensions: 440 x 350 x 320 mm
The M2009 model is a high-backed monocoque that allows the user to enjoy the sporting event in comfort, without sacrificing solidity and robustness.
Its 3 attachment points guarantee solidity, sturdiness and resistance to vandalism.
The M2009 model is:
- compliant with UEFA regulations;
- tested with laboratory tests by the largest Italian Institute for Research and Testing in the wood-furniture sector according to the European standard UNI EN 12727:2017 (level 4 - severe).
Monocoque seats
M2010
Dimensions: 420 x 320 x 400 mm
The M2010 is a high-backed monocoque that allows the user to enjoy the sporting event in maximum comfort, without sacrificing solidity and sturdiness.
It is considered the monocoque with the best quality/price ratio in the market. Its depth of 400 mm is adaptable to most existing and/or newly built bleachers. Its 4 attachment points give guarantees of solidity, strength and vandal resistance.
Compliant with the latest FIFA / UEFA regulations and FIBA approved complying with the European UNI EN 13200-1-4 standards; laboratory tested by the largest Italian Institute for research and testing in the wood-furniture sector according to the European standard UNI EN 12727:2017 (level 4 - severe).
Monocoque seats
M2011
Dimensions: 430 x 340 x 450 mm
The M2011 - M2011/SMALL model is a monocoque with a double-pitch high back that allows the user to enjoy the sporting event in maximum comfort, without sacrificing solidity and sturdiness.
Compliant with the latest FIFA / UEFA regulations and FIBA approved; complying with European UNI EN 13200-1-4 standards; laboratory tested by Italy's largest research and testing institute in the wood-furniture sector according to European standard UNI EN 12727:2017 (level 4 - severe).
The surface of the seat is shiny smooth for easy cleaning; in the backrest only there are horizontal lines that make the surface of the backrest non-slip. In a highly visible position on the front, a logo, sponsor, etc., can be inserted from mold; alternatively, by means of an aluminum plate fastened with pop rivets.
Monocoque seats
M2020
The M2020 model is a brand new bucket seat, Italian design, with a high back, characterized by harmonious lines and
modern ergonomics. It has a solid base with transverse / longitudinal reinforcement ribs that allow the user to enjoy
the sporting event in maximum comfort, without sacrificing quality and strength.
Its main peculiarity is its versatility, in fact its depth can vary from 320 to 400 mm, making it adaptable to most existing
or newly built steps.
Its 2/4/6 fixing points and thicknesses up to 20 mm make the seat solid and particularly resistant to vandalism.
Dimensions: depth 320/350/400 mm; width 420 mm; backrest height 330 mm.
Monocoque seats
M2025
M2025 is a brand new bucket seat, Italian design, with a high back, dimensionally compliant with the latest FIFA 2030 recommendations which require a center to center minimum of 500 mm and consequently greater width and usability.
Its main peculiarity is its versatility, in fact its width can vary from 460 to 480 mm, and its depth can vary from
350 / 400 / 450 mm, making it adaptable to most existing or newly built steps. 2025 its characterized by harmonious lines and modern ergonomics It has a solid base with transverse / longitudinal reinforcement ribs that allow the user to enjoy the sporting event in maximum comfort, without sacrificing quality and strength.
Dimensionally complying with FIFA 2030 / UEFA CAF
Recycled plastic option available upon request
Monocoque seats
M90
Dimensions: 400 x 110 x 350 mm
Model M90 is a Stadium seat without backrest which grants the user to enjoy the sport event in the maximum comfort
without sacrificing strength and durability.
Complying with the European standards UNI EN 13200-1-4, tested by appropriate national and certified labs, specialized with wood and furniture. M90 also complies with European standards UNI EN 12727:2017 (level 4 – severe).
Injection moulded with first quality coloured copolymer polypropylene, fire resistant reaction class 1, also addicted with
Anti-UV treatment (standard or long range) to ensure maximum resistance to UV insulation rate.
Seat is composed of a solid base with transversal reinforcement ribs and increased thickness next to the fixing points.
The surface is smooth and shiny to facilitate cleaning operations. The drainage hole is provided in the central part of
the seat and prevents water and dirt stagnation. Curved front edge with right-angle base overlapping terrace front.
Fixing holes are protected by appropriate vandalism proof closing covers provided in the same color of the seat
Seat numbers, 45x18 mm are made with plastic material (or aluminium) and are located in the appropriate slot in the
front part of the seat for easier viewing from below by climbing the steps. The plate is fixed using n.2 rivets 3,2x7 mm.
Installation options:
1.Direct on concrete step in 2 points with M8 anchors;
2.Riser mounted on a polyamide or metal bracket in 3 points using M8 anchors;
3.Floor mounted on metal beam fixed to the step floor in 4 points with M8 anchors;
Tip-up seats
Caravaggio
Dimensions: 450 x 400 x 490 mm
Caravaggio the new seat designed by Pininfarina, is designed to offer spectators a solution focused on design, elegance and quality, resulting in an aesthetically harmonious product that is also extremely comfortable and functional, characterized by simple and essential yet refined lines, the perfect combination of comfort and luxury.
A project inspired by innovation, technological research and great attention to the environment; in fact, Caravaggio is a folding seat with seat and backrest produced with injection-moulded copolymer polypropylene derived from waste from separate and/or industrial waste collection (PSV version), certified by IPPR (Institute for the Promotion of Plastics from Recycling) fireproof and additivated in the mass with UV-resistant substance.
Compliant with FIFA / UEFA regulations; complying with European standards UNI EN 13200-1-4, certified with laboratory tests according to European standard UNI EN 12727:2017 (level 4 - severe).
Tip-up seats
M2012
Dimensions: 470 x 660 x 300 mm
The M2012 model is an armchair conceived and designed for use in sports facilities all over the world.
FIBA homologated and compliant with the latest FIFA and UEFA regulations; compliant with European UNI EN13200-1-4 standards; laboratory tested by the largest Italian Institute for Research and Testing in the wood-furniture sector according to
European standard UNI EN 12727:2017 (level 4 - severe).
The supporting structure is made of fireproof polyamide reinforced with glass fibre (moulded using injection technology), the reinforcement ribs placed inside the supporting structure give it a strength equal to a steel structure.
The characteristics of polyamide also make the M2012 small armchair particularly suitable for areas with high humidity and salt concentration.
Tip-up seats
M2013
Dimensions: 480 x 540 x 150 mm
M2013 is not just a revolutionary folding seat, but a family of products suitable to be placed in all areas of a stadium: from the general spectator to the hospitality area via the VIP, Business and the exclusive VVIP area.
Design, comfort, robustness and safety. These are the key words to describe a product that responds to the needs of the end user, tastes and trends of today's world.
Compliant with the latest FIFA / UEFA regulations and FIBA homologated; compliant with European standards UNI EN 13200-1-4; laboratory tested by the largest Italian Institute for Research and Testing in the wood-furniture sector (CATAS) according to European standard UNI EN 12727:2017 (level 4 - severe).
Tip-up seats
M2016
Dimensions: 450 x 450 x 450 mm
M2016 is a revolutionary tip-up of the latest generation; thanks to its size and technical qualities, it can be placed in all areas of a stadium, even where the characteristics of the tier do not allow the installation of tip-up seats, all without compromising design, comfort and robustness.
Conforms to FIFA / UEFA regulations; FIBA approved, complying with European standards UNI EN 13200-1-4, certified with laboratory tests according to European standard UNI EN 12727:2017 (level 4 - severe).
Folding of the seat is done with a special “Double Spring” device, all not visible and not accessible as it is located in special closed compartment.
Tip-up seats
M2027
The model M2027 is a folding seat thought and designed for its use in sports facilities worldwide. Tip-up seat which meets FIFA 2030 and UEFA CAF recommendations and approved by FIBA; it complies with the European standard EN 13200-1-4; tested by the largest Italian institute for research and testing in the wood-furniture sector according to European standard EN 12727: 2017 (level 4 - severe). The structure is made of fire-resistant glass fiber reinforced polyamide (manufactured with injection technology), stiffening ribs placed inside the bearing structure provide a strength equal to a steel structure. The wraparound shape of the seat and backrest in polypropylene (manufactured with injection technology) applied on the structure and fixed to the support by means of blind rivets (4,8x12 head 16 with seal breaking load in traction of 3050 N and a load of shear failure of 2150 N.) make the whole chair extremely resistant to vandalism, particularly resistant to vandalism with no visible screws. The characteristics of polyamide make the M2027 also particularly suitable for areas with high humidity and salt concentration.
VIP Armchairs
Botticelli
Dimensions: 600 x 440 x 600 mm
Botticelli is the Italian design sport seat characterized by enveloping ergonomics; ideal to be used in the most
prestigious areas of a sports facility or for players/referee benches, hospitality boxes, hospitality lounges, stages,
dressing and conference rooms.
The Botticelli chair enables a correct posture and ensures a comfortable sitting position even after many hours,
thanks to solid seat and back padding which provides lumbar and cervical support.
The solid metal structure is covered with high-density polyurethane foam, the backrest and fixed seat are in
washable eco leather, the headrest is integrated, the sides are fully upholstered and the stitching is highly
resistant; It provides several clearly visible spaces for placing logos or writings and allows a wide choice of color
combinations.
It gives particular importance to the environment’s care, being recyclable and thanks to the use of recycled materials, it complies with FIFA 2030 / UEFA CAF provisions, with the European regulations UNI EN 13200 1-4 and
it is tested according to the European standard UNI EN 12727
Dimensions: min. centre-to-centre distance 600 mm, depth 620 mm, seat height from 440 to 450 mm, width 600
mm, total height 980 mm.
VIP Armchairs
Leonardo Gold
Dimensions: 690 x 1220 x 480 mm
A new armchair with modern and elegant lines, the perfect combination of comfort and luxury and the highest level of quality and robustness.
A unique Italian design that stems from Pininfarina's extensive experience in the automotive sector, which has always been attentive to passenger comfort, here translated into an armchair characterised by a completely closed side that masks the structural elements, merging style and functionality thanks to the search for high-performance materials, even in unfavourable atmospheric conditions and high humidity.
An armchair that takes care of spectators' wellbeing, guaranteeing maximum safety also thanks to the use of fireproof materials, and capable of bringing families back to stadiums, allowing them to fully experience great emotions.
VIP chairs are customizable.
width 690 mm (with double armrest) seat width 500 mm
depth with closed seat 480 mm depth with open seat 670 mm
total height of the armchair 1220 mm
VIP Armchairs
Leonardo Silver
Dimensions: 650 x 1000 x 480 mm
A new armchair with modern and elegant lines, the perfect combination of comfort and luxury and the highest level of quality and robustness.
A unique Italian design that stems from Pininfarina's extensive experience in the automotive sector, which has always been attentive to passenger comfort, here translated into an armchair characterised by a completely closed side that masks the structural elements, merging style and functionality thanks to the search for high-performance materials, even in unfavourable atmospheric conditions and high humidity.
An armchair that takes care of spectators' wellbeing, guaranteeing maximum safety also thanks to the use of fireproof materials, and capable of bringing families back to stadiums, allowing them to fully experience great emotions.
VIP chairs are customizable.
